本脚本在 RouterOS 7.20.7 系统，家庭（几台设备，单电信出口）/单位（几百台设备，多电信出口）上测试，效果良好。
优点：
1.多ISP（即多出口）可以一次性完成配置，可以自适应流量控制，下载流量不抢占网页流量等资源，最大化利用带宽。
2.只限制所设置的出口WAN的流量，如果有内部专网（城域网或教育专网）时，专网的流量不会有限制。（网上部分脚本会限制网桥或LAN口的总速率，造成不需要限速的专网也被限制）
3.小包、实时通讯、网络游戏的部分端口优先级最高。
4.网页 HTTP/HTTPS 流量优先级次之。
5.大文件、长流量传输的优先级较低。
6.UDP大包（一般用于P2P传输）优先级最低。
使用方法：
1.下载 queue_tree 脚本文件，解压后得到 queue_tree.rsc
2.用记事本打开 queue_tree.rsc 文件，配置 外网接口 与 内网接口名称，再配置宽带的最大上行与下行速率，一般可在最高能跑到的速率再低10-20M左右为佳，这样可以预留一定的冗余给需要的流量，同时单种类型的流量也基本能跑满带宽。
3.将原有的 Mangle 标记先清理干净。（因为使用到 Mangle 标记，所以不能开启 fasttrack 功能）
4.将 queue_tree.rsc 上传到 RouterOS 中，打开 New Terminal 命令行窗口，使用 import file-name=queue_tree.rsc 来导入。（或者在 System->Scripts 中创建一个脚本，将内容复制进去，然后运行该脚本。）
# 在这里设置您的外网接口列表名称（所设置外网接口必须存在，如果有多个则用逗号分隔，比如：WAN1,WAN2）
:local pppoeInterfaces "pppoe-out1"
# 设置网关所在接口名称（用于下载队列根，一般为bridge1或内网接口名）
:local bridgeInterface "bridge1"
# 最大下载带宽与最大上传带宽，一般可在最高能跑到的速率再低10-20M左右为佳，这样可以预留一定的冗余给需要的流量，同时单种类型的流量也基本能跑满带宽。
# 设置最大下载带宽，请根据实际网络带宽修改。（单位：Mbps，如果外网接口有多个，也可以设置多个速度，中间用逗号分开）
:local maxDownloadMbps 220
# 设置最大上传带宽，请根据实际网络带宽修改。（单位：Mbps，如果外网接口有多个，也可以设置多个速度，中间用逗号分开）
:local maxUploadMbps 100
:local interfaceList [:toarray $pppoeInterfaces]
:local speedDownloadList [:toarray $maxDownloadMbps]
:local speedUploadList [:toarray $maxUploadMbps]
:local defaultDownloadSpeed ($speedDownloadList->0)
:local defaultUploadSpeed ($speedUploadList->0)
# ==================== 检查接口是否存在 ====================
# 检查pppoeInterfaces中的每个接口
:foreach i in=$interfaceList do={
:log info "正在检查接口 $i 是否存在..."
:if ([/interface find name=$i] = "" && [/interface list member find list=$i] = "") do={
:error "Interface '$i' not found"
}
}
# 检查桥接接口
:if ([/interface find name=$bridgeInterface] = "") do={
:error "Interface '$bridgeInterface' not found"
}
# 清空 Mangle 列表(IPv4)
:log info "正在清理 Mangle(IPv4) 列表原有标记。"
/ip firewall mangle remove [find comment~"Mark|Download|Upload"]
# 首先创建所有连接标记规则（只需要创建一次）
/ip firewall mangle
add action=mark-connection chain=prerouting comment="Mark HTTP Connections" dst-port=80,8080,8000,8081,443,8443 new-connection-mark=http_conn protocol=tcp
add action=mark-connection chain=prerouting comment="Mark TCP Connections" connection-mark=!http_conn new-connection-mark=tcp_conn protocol=tcp
# 将接口列表转换为数组并遍历
:foreach interface in=$interfaceList do={
# 下载方向规则
add action=mark-packet chain=forward comment="Download Real-time UDP Packets ($interface)" src-port=53,3478,3479,3659,5060,27000-27050 in-interface=$interface new-packet-mark="dl_realtime($interface)" passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Download UDP Small Packets ($interface)" in-interface=$interface new-packet-mark="dl_udp_small($interface)" packet-size=0-512 passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Download UDP Large Packets ($interface)" in-interface=$interface new-packet-mark="dl_udp_large($interface)" passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Download Large File Packets ($interface)" connection-bytes=5000000-0 in-interface=$interface new-packet-mark="dl_large_file($interface)" passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Download HTTP Packets ($interface)" connection-mark=http_conn in-interface=$interface new-packet-mark="dl_http($interface)" passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Download TCP Small Packets ($interface)" connection-mark=tcp_conn in-interface=$interface new-packet-mark="dl_tcp_small($interface)" packet-size=0-128 passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Download Other TCP Packets($interface)" in-interface=$interface new-packet-mark="dl_other_tcp($interface)" passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Download ICMP Packets($interface)" in-interface=$interface new-packet-mark="dl_icmp($interface)" passthrough=no protocol=icmp
# 上传方向规则
add action=mark-packet chain=forward comment="Upload Real-time UDP Traffic Packets ($interface)" dst-port=53,3478,3479,3659,5060,27000-27050 new-packet-mark="up_realtime($interface)" out-interface=$interface passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Upload UDP Small Packets ($interface)" new-packet-mark="up_udp_small($interface)" out-interface=$interface packet-size=0-512 passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Upload UDP Large Packets ($interface)" new-packet-mark="up_udp_large($interface)" out-interface=$interface passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Upload Large File Traffic Packets ($interface)" connection-bytes=5000000-0 new-packet-mark="up_large_file($interface)" out-interface=$interface passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Upload HTTP Traffic Packets ($interface)" connection-mark=http_conn new-packet-mark="up_http($interface)" out-interface=$interface passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Upload TCP Small Packets ($interface)" connection-mark=tcp_conn new-packet-mark="up_tcp_small($interface)" out-interface=$interface packet-size=0-128 passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Upload Other TCP Packets ($interface)" new-packet-mark="up_other_tcp($interface)" out-interface=$interface passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Upload ICMP Packets($interface)" out-interface=$interface new-packet-mark="up_icmp($interface)" passthrough=no protocol=icmp
:log info "接口 $interface 上的 Mangle(IPv4) 标记创建完成。"
}
:log info "所有接口 $pppoeInterfaces 上的 Mangle(IPv4) 标记已经创建完成。"
# 清空 Mangle 列表(IPv6)
:log info "正在清理 Mangle(IPv6) 列表原有标记。"
/ipv6 firewall mangle remove [find comment~"Mark|Download|Upload"]
# 首先创建所有连接标记规则（只需要创建一次）
/ipv6 firewall mangle
add action=mark-connection chain=prerouting comment="Mark HTTP Connections" dst-port=80,8080,8000,8081,443,8443 new-connection-mark=http_conn protocol=tcp
add action=mark-connection chain=prerouting comment="Mark TCP Connections" connection-mark=!http_conn new-connection-mark=tcp_conn protocol=tcp
# 将接口列表转换为数组并遍历
:foreach interface in=$interfaceList do={
# 下载方向规则
add action=mark-packet chain=forward comment="Download Real-time UDP Packets ($interface)" src-port=53,3478,3479,3659,5060,27000-27050 in-interface=$interface new-packet-mark="dl_realtime($interface)" passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Download UDP Small Packets ($interface)" in-interface=$interface new-packet-mark="dl_udp_small($interface)" packet-size=0-512 passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Download UDP Large Packets ($interface)" in-interface=$interface new-packet-mark="dl_udp_large($interface)" passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Download Large File Packets ($interface)" connection-bytes=5000000-0 in-interface=$interface new-packet-mark="dl_large_file($interface)" passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Download HTTP Packets ($interface)" connection-mark=http_conn in-interface=$interface new-packet-mark="dl_http($interface)" passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Download TCP Small Packets ($interface)" connection-mark=tcp_conn in-interface=$interface new-packet-mark="dl_tcp_small($interface)" packet-size=0-128 passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Download Other TCP Packets($interface)" in-interface=$interface new-packet-mark="dl_other_tcp($interface)" passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Download ICMP Packets($interface)" in-interface=$interface new-packet-mark="dl_icmp($interface)" passthrough=no protocol=icmp
# 上传方向规则
add action=mark-packet chain=forward comment="Upload Real-time UDP Traffic Packets ($interface)" dst-port=53,3478,3479,3659,5060,27000-27050 new-packet-mark="up_realtime($interface)" out-interface=$interface passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Upload UDP Small Packets ($interface)" new-packet-mark="up_udp_small($interface)" out-interface=$interface packet-size=0-512 passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Upload UDP Large Packets ($interface)" new-packet-mark="up_udp_large($interface)" out-interface=$interface passthrough=no protocol=udp
add action=mark-packet chain=forward comment="Upload Large File Traffic Packets ($interface)" connection-bytes=5000000-0 new-packet-mark="up_large_file($interface)" out-interface=$interface passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Upload HTTP Traffic Packets ($interface)" connection-mark=http_conn new-packet-mark="up_http($interface)" out-interface=$interface passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Upload TCP Small Packets ($interface)" connection-mark=tcp_conn new-packet-mark="up_tcp_small($interface)" out-interface=$interface packet-size=0-128 passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Upload Other TCP Packets ($interface)" new-packet-mark="up_other_tcp($interface)" out-interface=$interface passthrough=no protocol=tcp
add action=mark-packet chain=forward comment="Upload ICMP Packets($interface)" out-interface=$interface new-packet-mark="up_icmp($interface)" passthrough=no protocol=icmp
:log info "接口 $interface 上的 Mangle(IPv6) 标记创建完成。"
}
:log info "所有接口 $pppoeInterfaces 上的 Mangle(IPv6) 标记已经创建完成。"
# ==================== 清理现有配置 ====================
:log info "开始清理现有的队列配置..."
/queue type remove [find name~"PCQ-"]
/queue tree remove [find]
:log info "队列配置清理完成"
# ==================== 创建队列类型 ====================
:log info "创建队列类型..."
/queue type
add kind=pcq name=PCQ-Download pcq-classifier=dst-address
add kind=pcq name=PCQ-Upload pcq-classifier=src-address
# 如果内网用户较多时，比较学校等机构中，10000KiB可以适当再改大
set [find name="PCQ-Download"] pcq-total-limit=10000KiB
set [find name="PCQ-Upload"] pcq-total-limit=10000KiB
# ==================== 为每个PPPoE接口创建队列树 ====================
# 将接口列表转换为数组并遍历
:for idx from=0 to=([:len $interfaceList] - 1) do={
:local interface ($interfaceList->$idx)
:if ($idx < [:len $speedDownloadList]) do={
:set defaultDownloadSpeed ($speedDownloadList->$idx)
}
:if ($idx < [:len $speedUploadList]) do={
:set defaultUploadSpeed ($speedUploadList->$idx)
}
:log info "为接口 $interface 创建队列树配置..."
#=================== 计算出常用的带宽 =================
:local downloadMbps100 ($defaultDownloadSpeed . "M")
:local downloadMbps75 ((($defaultDownloadSpeed *3 / 4 +5)/10*10) . "M")
:local downloadMbps50 ((($defaultDownloadSpeed / 2 +5)/10*10) . "M")
:local downloadMbps25 ((($defaultDownloadSpeed / 4 +5)/10*10) . "M")
:local uploadMbps100 ($defaultUploadSpeed . "M")
:local uploadMbps75 ((($defaultUploadSpeed *3 / 4 +5) /10*10) . "M")
:local uploadMbps50 ((($defaultUploadSpeed / 2 +5) /10*10) . "M")
:local uploadMbps25 ((($defaultUploadSpeed / 4 +5) /10*10) . "M")
# ==================== 下载队列树 ====================
/queue tree
# 下载根队列（所有下载流量共享同一个根，基于桥接接口）
add name="download_root($interface)" parent=$bridgeInterface priority=1 queue=default
# TCP小包（最高优先级）
add burst-limit=$downloadMbps75 burst-threshold=$downloadMbps25 burst-time=30s limit-at=2M max-limit=\
$downloadMbps50 name="tcp_small_dl($interface)" packet-mark="dl_tcp_small($interface)" parent="download_root($interface)" \
priority=1 queue=default
# 实时UDP流量（最高优先级）
add burst-limit=$downloadMbps75 burst-threshold=$downloadMbps25 burst-time=30s limit-at=2M \
max-limit=$downloadMbps50 name="realtime_dl($interface)" packet-mark="dl_realtime($interface)" parent=\
"download_root($interface)" priority=1 queue=default
# UDP小包（高优先级）
add burst-limit=$downloadMbps75 burst-threshold=$downloadMbps25 burst-time=30s limit-at=2M \
max-limit=$downloadMbps50 name="udp_small_dl($interface)" packet-mark="dl_udp_small($interface)" parent=\
"download_root($interface)" priority=2 queue=default
# ICMP（高优先级）
add burst-limit=$downloadMbps75 burst-threshold=$downloadMbps25 burst-time=30s limit-at=2M \
max-limit=$downloadMbps50 name="icmp_dl($interface)" packet-mark="dl_icmp($interface)" parent=\
"download_root($interface)" priority=2 queue=default
# HTTP流量（中优先级）
add limit-at=5M max-limit=$downloadMbps100 name="http_dl($interface)" packet-mark="dl_http($interface)" \
parent="download_root($interface)" priority=3 queue=PCQ-Download
# 大文件流量（中低优先级）
add limit-at=5M max-limit=$downloadMbps100 name="large_file_dl($interface)" packet-mark="dl_large_file($interface)" \
parent="download_root($interface)" priority=6 queue=PCQ-Download
# UDP大包（低优先级）
add limit-at=5M max-limit=$downloadMbps100 name="udp_large_dl($interface)" packet-mark="dl_udp_large($interface)" \
parent="download_root($interface)" priority=7 queue=PCQ-Download
# 其他TCP流量（中低优先级）
add limit-at=2M max-limit=$downloadMbps100 name="other_tcp_dl($interface)" packet-mark="dl_other_tcp($interface)" \
parent="download_root($interface)" priority=5 queue=PCQ-Download
# ==================== 上传队列树 ====================
# 上传根队列 - 直接使用接口名称作为parent
add name="upload_root($interface)" parent=$interface priority=1 queue=default
# TCP小包上传（最高优先级）
add limit-at=1M max-limit=$uploadMbps50 name="tcp_small_ul($interface)" packet-mark="up_tcp_small($interface)" \
parent="upload_root($interface)" priority=1 queue=default
# 实时UDP流量上传（最高优先级）
add limit-at=1M max-limit=$uploadMbps50 name="realtime_ul($interface)" packet-mark=\
"up_realtime($interface)" parent="upload_root($interface)" priority=1 queue=default
# UDP小包上传（高优先级）
add limit-at=1M max-limit=$uploadMbps50 name="udp_small_ul($interface)" packet-mark="up_udp_small($interface)" \
parent="upload_root($interface)" priority=2 queue=default
# ICMP（高优先级）
add limit-at=1M max-limit=$uploadMbps50 name="icmp_ul($interface)" packet-mark="up_icmp($interface)" \
parent="upload_root($interface)" priority=2 queue=default
# HTTP流量上传（中优先级）
add limit-at=2M max-limit=$uploadMbps100 name="http_ul($interface)" packet-mark="up_http($interface)" \
parent="upload_root($interface)" priority=3 queue=PCQ-Upload
# 大文件流量上传（中优先级）
add limit-at=2M max-limit=$uploadMbps100 name="large_file_ul($interface)" packet-mark="up_large_file($interface)" \
parent="upload_root($interface)" priority=5 queue=PCQ-Upload
# UDP大包上传（低优先级）
add limit-at=1M max-limit=$uploadMbps100 name="udp_large_ul($interface)" packet-mark="up_udp_large($interface)" \
parent="upload_root($interface)" priority=6 queue=PCQ-Upload
# 其他TCP流量上传（中优先级）
add limit-at=1M max-limit=$uploadMbps100 name="other_tcp_ul($interface)" packet-mark="up_other_tcp($interface)" \
parent="upload_root($interface)" priority=5 queue=PCQ-Upload
:log info "接口 $interface 的队列树配置创建完成"
}
